VOE 11417128
| Availability: | |
|---|---|
| Item | Specification |
|---|---|
| Part Number | 20GPL (also VOE 11417128) |
| Product Name | General Purpose Bucket Tooth |
| Product Type | Wheel Loader Bucket Tooth / Ground Engaging Tool (GET) |
| Compatible Machine Models | Volvo L180 Series Wheel Loader |
| Application | General purpose loading and digging |
| Design | General Purpose (GPL) |
| Single Weight | 5.7 kgs (12.6 lbs) |
| Material | High-strength, wear-resistant alloy steel |
| Compatible Adapter System | Volvo 20 Series |
| Compatible Pin | 20P (Locking pin for secure attachment) |
| Industry Focus | Quarrying, Construction, Aggregate Handling, General Excavation |
| OEM Interchangeability | Direct replacement for Volvo OEM tooth |
Volvo 20GPL bucket tooth
VOE 11417128 general purpose tooth
L180 wheel loader bucket teeth
20 series Volvo GET tooth
5.7 kg loader tooth
Replacement tooth for Volvo L180 loader
20P locking pin for Volvo tooth
Volvo L180 general purpose tooth
The Volvo 20GPL General Purpose Bucket Tooth (Part No. VOE 11417128) is a genuine OEM-specification ground engaging tool designed specifically for the Volvo L180 series wheel loaders. Engineered as part of the Volvo 20 Series tooth system, this GPL (General Purpose Loader) tooth offers an optimal balance of penetration and wear resistance for a wide range of general excavation and loading applications.
The tooth features a self-sharpening design and is manufactured from high-quality alloy steel with a hardness of approximately 500 Brinell, depending on tooth type and size. This specific steel alloy is strategically selected to provide the right balance between hardness and tensile strength, ensuring maximum wear life and maintained performance in demanding conditions.
| Feature | Benefit |
|---|---|
| General Purpose (GPL) Profile | Versatile design suitable for a wide range of materials from loose aggregate to compacted soils |
| Self-Sharpening Design | Maintains penetration capability throughout the life of the tooth |
| High-Quality Steel Alloy | Excellent wear resistance and durability in abrasive conditions |
| Volvo 20 Series System | Perfect fit and maximum performance with Volvo adapters |
| Strategically Placed Wear Material | Extends service life in high-wear areas |
| Compatible with 20P Locking Pin | Easy installation and removal with vertical patented locking device |
| Equipment Class | Typical Applications |
|---|---|
| Volvo L180 Wheel Loader | Quarry loading, gravel handling, sand and aggregate work |
| General Construction | Stockpile loading, site preparation, material handling |
| Light to Medium Excavation | Loam, topsoil, clay, and compacted fills |
The 20GPL tooth is specifically matched to Volvo L180 series wheel loaders, including:
Volvo L180 (Base model)
Volvo L180C
Volvo L180D
Volvo L180E
Volvo L180F
Volvo L180G
Volvo L180H
The L180 series features an operating weight of approximately 19,500–23,000 kg with bucket capacities ranging from 3.0 m³ to 5.5 m³ depending on configuration.
Adapter Compatibility: Ensure installation on Volvo 20 Series adapter only
Pin Installation: Use correct 20P locking pin; vertical patented locking device enables fast, hammerless installation
Regular Inspection: Check tooth wear periodically; replace when significant wear occurs
Complete System: Replace all teeth as a set for even wear and consistent performance
Genuine Fit: Exact OEM specifications for perfect fitment with 20 Series adapters
Proven Performance: Up to 20% more penetration over life of the tooth
Versatile Application: Ideal all-round choice for varied materials
Cost-Effective: Lower fuel consumption, reduced wear on bucket and machine components
| Item | Detail |
|---|---|
| Part Number | 20GPL / VOE 11417128 |
| Type | General Purpose (GPL) |
| Series | 20 Series Volvo Tooth System |
| Weight | 5.7 kg per piece |
| Pin Required | 20P (order separately) |
| Packaging | Individual pieces or bulk |
Note: Must be used with Volvo 20 Series adapter and 20P locking pin. Replace pin when installing new tooth for optimal retention.
