LA15CR30
| Availability: | |
|---|---|
| Item | Specification |
|---|---|
| Part Number | LA15CR30 (also VOE 11417164) |
| Product Name | Bolt-On Corner Adapter |
| Product Type | Wheel Loader Bucket Adapter / Ground Engaging Tool (GET) |
| Application | Connects bucket teeth to the bucket corner using bolt-on attachment |
| Design | CR - Corner Adapter (Bolt-On) |
| Edge Thickness | 35 mm |
| Single Weight | 9.5 kgs (20.9 lbs) |
| Material | High-strength, heat-treated alloy steel |
| Compatible Tooth Series | Volvo 15 Series |
| Compatible Pin | 15P (Locking pin for secure attachment) |
| Industry Focus | Mid-size to large wheel loaders, General construction, Quarrying, Material handling |
| OEM Interchangeability | Direct replacement for Volvo OEM adapter |
| Compatible Machine Models | Volvo L90, L110, L120, L150 Series Wheel Loaders |
Volvo LA15CR30 bolt-on corner adapter
VOE 11417164 corner adapter
L90 L110 L120 L150 wheel loader corner adapter
Volvo CR adapter 15 series
35mm edge thickness corner adapter
9.5 kg Volvo GET adapter
15P locking pin compatible adapter
Bolt-on corner loader adapter
The Volvo LA15CR30 Bolt-On Corner Adapter (Part No. VOE 11417164) is a genuine OEM-specification ground engaging tool adapter designed specifically for Volvo mid-size to large wheel loaders. Engineered as part of the Volvo CR (Corner Adapter) series, this adapter provides a secure, bolted interface between the bucket corner and 15 Series ground engaging tools (teeth).
The "CR" (Corner Adapter) design features a bolt-on attachment method specifically engineered for bucket corner positions, providing enhanced strength and wear protection at the critical corner area where digging forces are highest. With a 35mm edge thickness rating and robust 9.5 kg construction, this corner adapter is designed for heavy-duty buckets on L90 through L150 wheel loaders in demanding applications.
| Feature | Benefit |
|---|---|
| Corner-Specific (CR) Design | Engineered specifically for bucket corner positions for maximum durability at high-stress points |
| Bolt-On Attachment | No welding required - simple bolted installation and replacement |
| 35mm Edge Thickness Compatibility | Designed for heavy-duty bucket edges on mid-size to large wheel loaders |
| Robust Construction (9.5 kg) | Heavy-duty build for demanding corner applications |
| High-Strength Alloy Steel | Maximum durability at critical corner wear points |
| Volvo 15 Series System | Compatible with 15 Series teeth and 15P locking pins |
| Precision Manufacturing | Ensures perfect fitment to OEM buckets |
| Corrosion Resistant Coating | Extended service life in various conditions |
| Easy Field Replacement | Adapters can be removed and replaced without specialized welding equipment |
| Feature | Standard Adapter (TL/FC/BN) | Corner Adapter (CR) |
|---|---|---|
| Position | Center/Intermediate | Bucket Corner |
| Load Stress | Moderate | Highest (corner forces) |
| Wear Protection | Standard | Enhanced |
| Weight | Lighter | Heavier for same edge thickness |
| Best Application | General digging | Corner protection, heavy digging |
| Part Number | Type | Edge Thickness | Weight | Best Application |
|---|---|---|---|---|
| LA15FC30 | FC (Flush) | 30 mm | 6.1 kg | Center position, material flow |
| LA15TL35 | TL (Top Leg) | 35 mm | 6.2 kg | Center position, durability |
| LA15BN35 | BN (Bolt-On) | 35 mm | 8.0 kg | Center position, bolt-on |
| LA15CR30 | CR (Corner) | 35 mm | 9.5 kg | Corner position, bolt-on |
The LA15CR30 corner adapter is specifically matched to Volvo mid-size to large wheel loaders with 35mm bucket edges, including:
Volvo L90 Series
Volvo L110 Series
Volvo L120 Series
Volvo L150 Series (L150, L150B, L150C, L150D, L150E, L150F, L150G)
These wheel loaders typically feature operating weights from 14,000 kg to 25,000 kg with bucket capacities from 2.5 m³ to 5.0 m³.
| Component | Part Number | Description |
|---|---|---|
| Compatible Teeth | 15GPL, 15GPE, 15AML, 15AMRL, 15AMXL, 15PPE, 15TPE, 15SNE | 15 Series teeth |
| Locking Pin | 15P | Vertical locking pin |
| Mounting Bolts | Refer to OEM manual | Required for installation |
Corner Positioning: CR adapters are specifically designed for bucket corner positions - do not use in center positions
No Welding Required: CR adapters are bolted directly to the bucket edge - no welding needed
Edge Preparation: Ensure 35mm bucket corner has pre-drilled holes matching the adapter bolt pattern
Bolt Torque: Use OEM-specified bolts and torque to recommended specifications
Pin Installation: Use correct 15P locking pin; vertical locking device enables fast, hammerless installation
Regular Inspection: Check bolts for tightness and adapters for wear periodically - corners wear faster than center positions
Tooth Compatibility: Use only with Volvo 15 Series teeth
Easy Replacement: When worn, unbolt the adapter and bolt on a new one - minimal downtime
Corner-Specific Design: Engineered specifically for the highest-stress positions on the bucket - the corners
Enhanced Corner Protection: Provides additional wear material where digging forces are greatest
No Welding Required: The bolt-on design eliminates the need for specialized welding equipment and personnel
Quick Replacement: Corner adapters typically wear faster than center adapters - bolt-on design allows rapid field replacement
Heavy-Duty Optimized: Designed for 35mm bucket edges, ideal for demanding quarry and construction applications
Mid-Size to Large Machine Compatible: Specifically engineered for Volvo's L90 through L150 wheel loader line
Volvo Genuine Quality: Manufactured to exact OEM specifications for perfect fit and performance
| Item | Detail |
|---|---|
| Part Number | LA15CR30 / VOE 11417164 |
| Type | CR - Corner Adapter (Bolt-On) |
| Edge Thickness | 35 mm |
| Weight | 9.5 kg per piece |
| Position | Bucket Corner |
| Pin Required | 15P (order separately) |
| Bolts Required | OEM-specified (order separately) |
| Installation | Bolt-on |
| Packaging | Individual or bulk |
Note: No welding required for installation. Use only with Volvo 15 Series teeth and 15P locking pins. This adapter is specifically designed for bucket corner positions - do not use in center or intermediate positions. Mounting bolts are not included - refer to OEM specifications for correct bolt size and torque values. Verify bucket corner hole pattern matches adapter before ordering.
