LA55TL65
| Availability: | |
|---|---|
| Item | Specification |
|---|---|
| Part Number | LA55TL65 (also VOE 11417117) |
| Product Name | Top Leg Adapter / Long Top Leg Adapter |
| Product Type | Wheel Loader Bucket Adapter / Ground Engaging Tool (GET) |
| Application | Connects bucket teeth to the bucket lip with extended top leg design |
| Design | TL - Top Leg / Long Top Leg (1 1/2" profile) |
| Edge Thickness | 65 mm |
| Single Weight | 26.6 kgs (58.6 lbs) |
| Material | High-strength, heat-treated alloy steel |
| Compatible Tooth Series | Volvo 55 Series |
| Compatible Pin | 55P (Locking pin for secure attachment) |
| Industry Focus | Ultra-large wheel loaders, Heavy mining, Severe quarrying, Mass excavation |
| OEM Interchangeability | Direct replacement for Volvo OEM adapter |
| Compatible Machine Models | Volvo L250, L350, L350H Series Wheel Loaders |
Volvo LA55TL65 top leg adapter
VOE 11417117 long top leg adapter
L250 L350 L350H wheel loader adapter
1 1/2 top leg adapter Volvo
Volvo TL adapter 55 series
65mm edge thickness adapter
26.6 kg Volvo GET adapter
55P locking pin compatible adapter
Extreme heavy duty top leg adapter
The Volvo LA55TL65 Top Leg Adapter (Part No. VOE 11417117) is a genuine OEM-specification ground engaging tool adapter designed specifically for Volvo ultra-large wheel loaders. Engineered as part of the Volvo TL (Top Leg) series, this adapter provides a robust, extended top leg interface between the bucket lip and 55 Series ground engaging tools (teeth).
The "TL" (Top Leg) design features an extended 1 1/2" top leg profile that provides additional strength and wear material compared to flush-mounted (FC) adapters. With a massive 65mm edge thickness rating and heavy-duty 26.6 kg construction, this adapter is designed for the most extreme heavy-duty buckets on Volvo's largest wheel loader platforms operating in the most severe mining and heavy quarrying applications.
| Feature | Benefit |
|---|---|
| Top Leg (TL) Design | Extended 1 1/2" top leg profile provides additional strength and wear material |
| 65mm Edge Thickness Compatibility | Designed for extreme heavy-duty bucket edges on ultra-large wheel loaders |
| Heavy-Duty Construction (26.6 kg) | Maximum durability for the most severe mining service conditions |
| High-Strength Alloy Steel | Exceptional durability for extreme applications |
| Volvo 55 Series System | Compatible with 55 Series teeth and 55P locking pins |
| Precision Manufacturing | Ensures perfect fitment to OEM buckets |
| Corrosion Resistant Coating | Extended service life in various conditions |
| Adapter Type | Profile | Best Application | Protrusion | Strength |
|---|---|---|---|---|
| FC (Flush-Mounted) | Low-profile, flush | Grading, material flow | Minimal | Standard |
| TL (Top Leg) | Extended top leg | General purpose, durability | Moderate | Enhanced |
| Part Number | Type | Edge Thickness | Weight | Best Application |
|---|---|---|---|---|
| LA55FC20 | FC | 20 mm | 21.0 kg | Flush mount, material flow |
| LA55FC25 | FC | 25 mm | 21.3 kg | Flush mount, material flow |
| LA55FC30 | FC | 30 mm | 21.6 kg | Flush mount, material flow |
| LA55FC35 | FC | 35 mm | 21.9 kg | Flush mount, material flow |
| LA55FC40 | FC | 40 mm | 22.2 kg | Flush mount, material flow |
| LA55FC50 | FC | 50 mm | 22.6 kg | Flush mount, material flow |
| LA55TL65 | TL | 65 mm | 26.6 kg | General purpose, extreme duty |
| LA55FC65 | FC | 65 mm | 23.0 kg | Flush mount, material flow |
The LA55TL65 adapter is specifically matched to Volvo ultra-large wheel loaders with 65mm bucket edges, including:
Volvo L250 Series (L250, L250D, L250E, L250F, L250G)
Volvo L350 Series (L350F, L350G, L350H)
These wheel loaders are Volvo's largest platforms, featuring operating weights from 35,000 kg to 54,000 kg with bucket capacities from 6.0 m³ to 10.0 m³.
| Component | Part Number | Description |
|---|---|---|
| Compatible Teeth | 55GPL, 55GPE, 55AML, 55AMRL, 55AMXL, 55PPE, 55TPE, 55SNE | 55 Series teeth |
| Locking Pin | 55P | Vertical locking pin |
Welding Required: TL adapters are typically weld-on components. Use qualified personnel and proper welding procedures.
Edge Preparation: Ensure 65mm bucket edge is clean and properly prepared before welding.
Pin Installation: Use correct 55P locking pin; vertical locking device enables fast, hammerless installation.
Regular Inspection: Check adapter welds and wear periodically.
Tooth Compatibility: Use only with Volvo 55 Series teeth.
Lifting Note: At 26.6 kg, use proper lifting techniques and mechanical assistance when handling.
Enhanced Durability: The extended top leg (1 1/2") design provides additional wear material and structural strength compared to flush-mounted adapters
Extreme Heavy-Duty Optimized: Designed for 65mm bucket edges on Volvo's largest wheel loaders, ideal for the most severe mining and heavy quarrying applications
Largest Machine Compatible: Specifically engineered for Volvo's L250 and L350 wheel loader line - the largest platforms in Volvo's wheel loader portfolio
Volvo Genuine Quality: Manufactured to exact OEM specifications for perfect fit and performance
Versatile Application: Suitable for extreme heavy mining, severe quarrying, mass excavation, and the most demanding general purpose applications
| Item | Detail |
|---|---|
| Part Number | LA55TL65 / VOE 11417117 |
| Type | TL - Top Leg / Long Top Leg (1 1/2") |
| Edge Thickness | 65 mm |
| Weight | 26.6 kg per piece |
| Pin Required | 55P (order separately) |
| Installation | Weld-on |
| Packaging | Individual or bulk |
Note: Proper welding procedures must be followed for installation. Use only with Volvo 55 Series teeth and 55P locking pins. TL adapters provide enhanced durability compared to FC adapters but have increased protrusion - select based on your application requirements. Due to the significant weight (26.6 kg), mechanical lifting assistance is required during installation.
