LA30BN40
| Availability: | |
|---|---|
| Item | Specification |
|---|---|
| Part Number | LA30BN40 (also VOE 11417115) |
| Product Name | Bolt-On Adapter / Bolt-On Corner Adapter |
| Product Type | Wheel Loader Bucket Adapter / Ground Engaging Tool (GET) |
| Application | Connects bucket teeth to the bucket lip using bolt-on attachment |
| Design | BN - Bolt-On |
| Edge Thickness | 40 mm |
| Single Weight | 11.7 kgs (25.8 lbs) |
| Material | High-strength, heat-treated alloy steel |
| Compatible Tooth Series | Volvo 30 Series |
| Compatible Pin | 30P (Locking pin for secure attachment) |
| Industry Focus | Large to ultra-large wheel loaders, Heavy mining, Severe quarrying, Mass excavation |
| OEM Interchangeability | Direct replacement for Volvo OEM adapter |
| Compatible Machine Models | Volvo L180, L220, L250, L350 Series Wheel Loaders |
Volvo LA30BN40 bolt-on adapter
VOE 11417115 bolt-on adapter
L180 L220 L250 L350 wheel loader adapter
Volvo BN adapter 30 series
40mm edge thickness adapter
11.7 kg Volvo GET adapter
30P locking pin compatible adapter
Bolt-on loader adapter
The Volvo LA30BN40 Bolt-On Adapter (Part No. VOE 11417115) is a genuine OEM-specification ground engaging tool adapter designed specifically for Volvo large to ultra-large wheel loaders. Engineered as part of the Volvo BN (Bolt-On) series, this adapter provides a secure, bolted interface between the bucket lip and 30 Series ground engaging tools (teeth).
The "BN" (Bolt-On) design features a bolt-on attachment method that eliminates the need for welding during installation or replacement, making it ideal for applications where adapters may need to be changed frequently or where welding is not practical. With a 40mm edge thickness rating and substantial 11.7 kg construction, this adapter is designed for heavy-duty buckets on L180 through L350 wheel loaders in severe mining and heavy quarrying applications.
| Feature | Benefit |
|---|---|
| Bolt-On (BN) Design | No welding required for installation or replacement - simple bolted attachment |
| 40mm Edge Thickness Compatibility | Designed for heavy-duty bucket edges on large to ultra-large wheel loaders |
| Substantial Construction (11.7 kg) | Heavy-duty build for severe service conditions |
| High-Strength Alloy Steel | Maximum durability for extreme applications |
| Volvo 30 Series System | Compatible with 30 Series teeth and 30P locking pins |
| Precision Manufacturing | Ensures perfect fitment to OEM buckets |
| Corrosion Resistant Coating | Extended service life in various conditions |
| Easy Field Replacement | Adapters can be removed and replaced without specialized welding equipment |
| Adapter Type | Attachment Method | Best Application | Replacement Ease |
|---|---|---|---|
| FC (Flush-Mounted) | Weld-on | Grading, material flow | Difficult (requires welding) |
| TL (Top Leg) | Weld-on | General purpose, durability | Difficult (requires welding) |
| BN (Bolt-On) | Bolt-on | Quick replacement, no welding | Easy (bolts only) |
| Part Number | Type | Edge Thickness | Weight | Best Application |
|---|---|---|---|---|
| LA30FC20 | FC | 20 mm | 11.2 kg | Flush mount, material flow |
| LA30FC25 | FC | 25 mm | 11.5 kg | Flush mount, material flow |
| LA30FC30 | FC | 30 mm | 11.9 kg | Flush mount, material flow |
| LA30FC35 | FC | 35 mm | 12.3 kg | Flush mount, material flow |
| LA30TL40 | TL | 40 mm | 12.0 kg | General purpose, durability |
| LA30BN40 | BN | 40 mm | 11.7 kg | Bolt-on, no welding |
| LA30FC40 | FC | 40 mm | 12.7 kg | Flush mount, material flow |
The LA30BN40 adapter is specifically matched to Volvo large to ultra-large wheel loaders with 40mm bucket edges, including:
Volvo L180 Series (L180, L180C, L180D, L180E, L180F, L180G, L180H)
Volvo L220 Series (L220, L220D, L220E, L220F, L220G, L220H)
Volvo L250 Series (L250, L250D, L250E, L250F, L250G)
Volvo L350 Series (L350F, L350G, L350H)
These wheel loaders typically feature operating weights from 20,000 kg to 54,000 kg with bucket capacities from 3.5 m³ to 10.0 m³.
| Component | Part Number | Description |
|---|---|---|
| Compatible Teeth | 30GPL, 30GPE, 30AML, 30AMRL, 30AMXL, 30PPE, 30TPE, 30SNE | 30 Series teeth |
| Locking Pin | 30P | Vertical locking pin |
| Mounting Bolts | Refer to OEM manual | Required for installation |
No Welding Required: BN adapters are bolted directly to the bucket edge - no welding needed.
Edge Preparation: Ensure 40mm bucket edge has pre-drilled holes matching the adapter bolt pattern.
Bolt Torque: Use OEM-specified bolts and torque to recommended specifications.
Pin Installation: Use correct 30P locking pin; vertical locking device enables fast, hammerless installation.
Regular Inspection: Check bolts for tightness and adapters for wear periodically.
Tooth Compatibility: Use only with Volvo 30 Series teeth.
Easy Replacement: When worn, unbolt the adapter and bolt on a new one - minimal downtime.
Lifting Note: At 11.7 kg, use proper lifting techniques when handling multiple units.
No Welding Required: The bolt-on design eliminates the need for specialized welding equipment and personnel
Quick Replacement: Adapters can be changed rapidly in the field, minimizing machine downtime
Heavy-Duty Optimized: Designed for 40mm bucket edges on large to ultra-large wheel loaders, ideal for severe mining and heavy quarrying applications
Large Machine Compatible: Specifically engineered for Volvo's L180 through L350 wheel loader line
Volvo Genuine Quality: Manufactured to exact OEM specifications for perfect fit and performance
Versatile Application: Suitable for severe quarrying, heavy mining, mass excavation, and demanding general purpose applications
| Item | Detail |
|---|---|
| Part Number | LA30BN40 / VOE 11417115 |
| Type | BN - Bolt-On |
| Edge Thickness | 40 mm |
| Weight | 11.7 kg per piece |
| Pin Required | 30P (order separately) |
| Bolts Required | OEM-specified (order separately) |
| Installation | Bolt-on |
| Packaging | Individual or bulk |
Note: No welding required for installation. Use only with Volvo 30 Series teeth and 30P locking pins. Mounting bolts are not included - refer to OEM specifications for correct bolt size and torque values. Verify bucket edge hole pattern matches adapter before ordering.
