DELA90X320-6R
| Availability: | |
|---|---|
| Item | Specification |
|---|---|
| Part Number | DELA90X320-6R |
| Product Name | Side Protector / Bucket Wing Shroud |
| Product Type | Excavator Bucket Wear Protection / Ground Engaging Tool (GET) |
| Compatible Machine Models | Hitachi EX1200-7 Mining Excavator |
| Position | Right Hand (RH) - Bucket Side / Wing |
| Application | Protects the bucket wing/side wall from severe abrasion and impact |
| Single Weight | 79 kgs (174.2 lbs) |
| Material | High-strength, abrasion-resistant alloy steel |
| Attachment Method | Weld-on or Bolt-on (OEM specification) |
| Industry Focus | Heavy Mining, Quarrying, Large-Scale Excavation |
Hitachi DELA90X320-6R side protector
EX1200-7 bucket wing shroud
EX1200-7 right hand wing shroud
Hitachi excavator bucket side protector
79 kg wing shroud for EX1200-7
Bucket side protection for mining
Replacement wing shroud for EX1200-7
DELA90X320-6R EX1200-7 wear parts
The Hitachi DELA90X320-6R Side Protector (Bucket Wing Shroud) is a genuine OEM-specification ground engaging tool designed for the Hitachi EX1200-7 mining excavator. This right-hand (RH) wing shroud provides essential protection to the bucket side wall, shielding it from severe abrasion and impact during heavy mining operations.
The EX1200-7 is a large mining excavator used in surface mining, quarrying, and heavy excavation. This wing shroud is manufactured from high-strength, abrasion-resistant alloy steel to withstand the most demanding conditions, extending bucket life by protecting critical side wall areas from premature wear.
| Feature | Benefit |
|---|---|
| Right Hand (RH) Configuration | Specifically designed for the right side of the bucket |
| Wing Shroud Design | Specifically shaped to protect bucket side wall and wing area |
| Abrasion-Resistant Alloy Steel | Maximum durability in severe mining conditions |
| EX1200-7 Optimized | Specifically engineered for Hitachi EX1200-7 mining excavator |
| Heavy-Duty Construction (79 kg) | Robust build for demanding mining applications |
| Direct OEM Replacement | Guaranteed fit and performance |
| Extended Bucket Life | Protects critical bucket structure from wear and impact |
| Specification | Detail |
|---|---|
| Machine Model | Hitachi EX1200-7 Mining Excavator |
| Machine Type | Large Mining Excavator |
| Position | Right Hand (RH) - Bucket Side / Wing |
| Operating Weight | ~110,000 - 120,000 kg |
| Bucket Capacity | ~6.0 - 8.0 m³ |
| Application | Surface mining, quarrying, heavy excavation |
| Component | Part Number / Position | Description |
|---|---|---|
| Left Side Wing Shroud | DELA90X320-6L (counterpart) | Left hand side protection |
| Lip Shrouds | Various | Bucket lip protection |
| Heel Shrouds | Various | Bucket heel protection |
| Teeth & Adapters | Various | Ground engaging tools |
Position: This is a right-hand (RH) side/wing protector - installs on right side of bucket
Lifting Note: At 79 kg, proper lifting techniques and mechanical assistance are recommended
Attachment: Follow Hitachi OEM specifications for welding or bolting
Regular Inspection: Check for wear, cracks, and loose attachment periodically
Replacement: Replace when worn beyond OEM specifications to protect bucket structure
Pair Replacement: Consider replacing both left and right shrouds simultaneously for balanced protection
| Condition | Action |
|---|---|
| New shroud - full profile | Normal operation |
| Moderate wear | Monitor regularly |
| Excessive wear (holes or thinning) | Replace shroud |
| Cracks or deformation | Replace immediately |
| Loose attachment | Retighten or re-weld |
| Item | Detail |
|---|---|
| Part Number | DELA90X320-6R |
| Type | Side Protector / Bucket Wing Shroud (Right Hand) |
| Weight | 79 kg per piece |
| Compatibility | Hitachi EX1200-7 Mining Excavator |
| Packaging | Individual crate |
Note: This is a right-hand (RH) bucket wing shroud for the Hitachi EX1200-7 mining excavator. The left-hand counterpart (DELA90X320-6L) is available separately. Verify machine model, bucket configuration, and attachment method before ordering. Due to weight (79 kg), proper lifting techniques and mechanical assistance are recommended during installation. Regular inspection and timely replacement of wing shrouds are essential to protect the bucket structure from premature wear and damage.
