ES6697-4
Product Specification: Heel Shroud/Protector for Bucket
| Item | Specification |
|---|---|
| Part Number | ES6697-4 (or ES66974, F10) |
| Product Name | Weld-On Heel Shroud / Bucket Heel Corner Protector |
| Product Type | Excavator / Shovel Bucket Heel Corner Wear Protection |
| Application | Protects the bucket heel corner from severe abrasion and impact |
| Design | Corner Protection |
| Single Weight | 9.5 kgs (20.9 lbs) |
| Material | High-strength, abrasion-resistant alloy steel |
| Attachment Method | Weld-On |
| Industry Focus | Mining, Quarrying, Heavy Excavation, Construction |
ES6697-4 heel shroud
F10 bucket heel protector
Weld-on heel shroud
9.5 kg corner heel shroud
Bucket heel corner protection
Mining bucket heel guard
Replacement heel shroud
Excavator heel wear part
The ES6697-4 (F10) Weld-On Heel Shroud is a genuine OEM-specification ground engaging tool designed to protect the bucket heel corner area from severe abrasion and impact in mining, quarrying, and heavy excavation applications. This corner heel shroud shields the critical rear corner area of the bucket, extending overall bucket service life.
Manufactured from high-strength, abrasion-resistant alloy steel, this heel protector is designed to withstand demanding conditions. The weld-on design ensures permanent attachment and robust protection.
| Feature | Benefit |
|---|---|
| Corner Heel Shroud Design | Specifically engineered for bucket heel corner protection |
| Weld-On Attachment | Secure permanent installation |
| Abrasion-Resistant Alloy Steel | Durability in demanding conditions |
| Lightweight Construction (9.5 kg) | Easy handling during installation |
| Direct OEM Replacement | Guaranteed fit and performance |
| Extended Bucket Life | Protects critical bucket corner structure from wear |
Position: Installs on the bucket heel corner area
Attachment: Weld-on installation - use qualified personnel and proper welding procedures
Lifting Note: At 9.5 kg, can be handled by one person with proper technique
Regular Inspection: Check for wear, cracks, and weld integrity periodically
Replacement: Replace when worn beyond OEM specifications to protect bucket structure
| Condition | Action |
|---|---|
| New shroud - full profile | Normal operation |
| Moderate wear | Monitor regularly |
| Excessive wear (holes or thinning) | Replace shroud |
| Cracks or deformation | Replace immediately |
| Weld cracks | Repair immediately |
| Item | Detail |
|---|---|
| Part Number | ES6697-4 / ES66974 / F10 |
| Type | Weld-On Heel Shroud (Corner Protection) |
| Weight | 9.5 kg per piece |
| Packaging | Individual box |
Note: This is a weld-on heel shroud for bucket heel corner protection. Weld-on installation required - use qualified welding personnel. Verify bucket model and configuration before ordering. Due to weight (9.5 kg), proper lifting techniques are recommended during installation. Regular inspection and timely replacement are essential to protect the bucket structure from premature wear.
