Product Specification:
Part Number: 395-1050 (also referenced as 3951050)
Product Name: Track Group Assembly / Lubricated Track Group
Product Type: Undercarriage Component / Complete Track Assembly
Number of Track Sections: 41
Shoe Width: 710 mm (28 inches)
Track Pitch: 317.5 mm (12.5 inches)
Master Link Type: 1 Tooth Master
Grouser Type: Single Grouser
Shoe Type: ES (Extreme Service)
Track System: SALT (Sealed and Lubricated Track)
Pin Retention: PPR (Positive Pin Retention)
Bolt Size: 1 3/8 inch
Assembly Weight: 6,214 kgs (13,700 lbs)
Compatible Machine Models: Caterpillar D11, Caterpillar D11T, Caterpillar D11N, Caterpillar D11R
Material: High-strength, wear-resistant alloy steel
Application: Mining, quarrying, heavy earthmoving, dozer undercarriage replacement
Note: For detailed installation procedures and torque specifications, please contact our sales team.
Key Features:
Complete Assembly: Fully assembled track group including links, shoes, and hardware ready for installation
41 Section Configuration: Full undercarriage track replacement for D11 series dozers
SALT Technology: Sealed and Lubricated Track seals lubricant into the undercarriage system and keeps abrasives out, eliminating internal pin and bushing wear
PPR System: Positive Pin Retention prevents end-play generation and helps ensure oil retention in high impact applications
Extreme Service Shoes: ES track shoes are stronger to resist bending and breaking, with more allowable wear material than moderate service track shoes
710mm Shoe Width: Provides stable ground contact and machine stability for D11 series dozers
Single Grouser Design: Provides reliable traction in varied ground conditions
Direct OEM Replacement: Designed to meet OEM specification replacement standards
Compatible Equipment:
Caterpillar D11 – Track-Type Tractor
Caterpillar D11N – Track-Type Tractor
Caterpillar D11R – Track-Type Tractor
Caterpillar D11T – Track-Type Tractor
Caterpillar D11T CD – Track-Type Tractor
Applications:
Replacement Information:
This track group serves as a direct aftermarket replacement with OEM reference 395-1050 for Caterpillar D11, D11N, D11R, and D11T track-type tractors. The complete SALT/PPR lubricated track assembly is engineered to meet OEM specification replacement requirements for undercarriage applications in mining and heavy earthmoving operations.
Disclaimer: Beneparts is not affiliated with Caterpillar. All trademarks are used for identification and compatibility reference purposes only.
Related Parts:
Track rollers, carrier rollers, and idlers for D11 series dozers
Sprockets and undercarriage hardware
Complete undercarriage kits available upon request
Additional track shoe widths available separately
FAQ:
Q: Is the 395-1050 a direct replacement for the OEM track group?
A: Yes, the 395-1050 is manufactured as an aftermarket replacement with OEM specification replacement standards for Caterpillar D11, D11N, D11R, and D11T track groups.
Q: What machines is this track assembly compatible with?
A: It is specifically designed for Caterpillar D11, D11N, D11R, D11T, and D11T CD track-type tractors. Verify compatibility with your specific undercarriage system before installation.
Q: What are the key specifications of this track group?
A: The assembly features 41 sections, 710mm shoe width, 317.5mm track pitch, single grouser, Extreme Service shoes, 1 tooth master link, SALT lubrication, and PPR pin retention.
Q: What does SALT mean?
A: SALT stands for Sealed and Lubricated Track. This system seals lubricant into the undercarriage system and keeps abrasives out, eliminating internal pin and bushing wear.
Q: What does PPR mean?
A: PPR stands for Positive Pin Retention. This system uses a metal retaining ring pressed into the groove between the pin and the link to prevent end-play generation and help ensure oil retention in high impact applications.
Q: What is the weight of the 395-1050 track group?
A: The single assembly weight is approximately 6,214 kgs (13,700 lbs).
Q: What is the lead time for this replacement part?
A: Please contact our sales team for current stock availability and shipping estimates.
