Product Specification: Serrated Grader Blade
| Item | Specification |
|---|---|
| Part Number | 100-4581 (or 1004581) |
| Product Name | Serrated Grader Blade |
| Product Type | Motor Grader Cutting Edge |
| Compatible Machine Models | Caterpillar 16M, 16G Motor Grader |
| Application | Heavy-duty grading and soil pulverization |
| Blade Dimensions (Thickness × Height × Length) | 35 mm × 254 mm × 2438.4 mm (1.38 in × 10 in × 96 in) |
| Edge Type | Serrated / Scalloped |
| Single Weight | 140 kgs (308.6 lbs) |
Note:
This serrated grader blade is designed for Caterpillar 16M and 16G motor graders, featuring a scalloped edge profile for enhanced material breakup and mixing.
The serrated design is ideal for pulverizing hard-packed soil, asphalt milling, and maintaining unpaved roads.
Standard 8-foot length (96 inches / 2438.4 mm) with 10-inch height and 35mm thickness for extended wear life.
Manufactured from through-hardened steel for optimal abrasion resistance and impact strength.
Please verify exact compatibility with your specific moldboard mounting configuration before installation.
If you need specification sheets for grader bits, end bits, or other related motor grader wear parts, please feel free to let us know.
