XSCW12RMHL
| Availability: | |
|---|---|
| Item | Specification |
|---|---|
| Part Number | XSCW12RMHL |
| Product Name | Mining Shovel Bucket Tooth (Crown Profile) |
| Product Type | Cable / Hydraulic Shovel Bucket Tooth (GET) |
| Tooth System | XSC12 Series |
| Profile | Crown |
| Compatible Machine Models | 495, 7495HD, WH12 Mining Shovels |
| Application | Extreme-duty mining and hard rock excavation |
| Single Weight | 137 kgs (302.0 lbs) |
| Material | High-strength, wear-resistant alloy steel |
| Industry Focus | Surface Mining, Hard Rock Excavation, Overburden Removal |
XSCW12RMHL shovel tooth
495HD bucket tooth
7495HD mining tooth
WH12 shovel tooth
Crown profile mining tooth
137 kg shovel tooth
XSC12 series tooth
Replacement tooth for 7495HD
The XSCW12RMHL Mining Shovel Bucket Tooth (Crown Profile) is a genuine OEM-specification ground engaging tool designed for the XSC12 tooth system, compatible with 495, 7495HD, and WH12 mining shovels. This Crown profile tooth is engineered for extreme-duty mining and hard rock excavation in the most demanding surface mining conditions.
The Crown profile provides an excellent balance of penetration and wear resistance for severe mining applications. The XSC12 system is designed for ultra-class mining shovels used in large-scale surface mining operations.
| Feature | Benefit |
|---|---|
| Crown Profile | Excellent balance of penetration and wear resistance |
| XSC12 System Design | Engineered for ultra-class mining shovels |
| High-Strength Alloy Steel | Superior toughness and wear resistance |
| Heavy-Duty Construction (137 kg) | Built for extreme mining conditions |
| Multi-Model Compatibility | Fits 495, 7495HD, WH12 shovels |
| Direct OEM Replacement | Guaranteed fit and performance |
| Machine Model | Type | Application |
|---|---|---|
| 495, 7495HD | Electric Rope Shovel | Surface mining, hard rock |
| WH12 | Mining Shovel | Surface mining, hard rock |
| Component | Description |
|---|---|
| Compatible Adapter | XSC12 series adapter |
| Locking Pin | XSC12PSL |
| Retention System | Pin-on attachment |
Adapter Compatibility: Use only with XSC12 series adapter
Pin Installation: Use correct XSC12PSL locking pin; ensure secure fit
Lifting Requirement: Due to weight (137 kg), mechanical lifting assistance is required for safe handling
Regular Inspection: Check tooth for wear and damage periodically
Replacement: Replace when worn beyond OEM specifications
| Condition | Action |
|---|---|
| New tooth - full profile | Normal operation |
| Moderate wear | Monitor regularly |
| Excessive wear (loss of profile) | Replace tooth |
| Broken or cracked tooth | Replace immediately |
| Item | Detail |
|---|---|
| Part Number | XSCW12RMHL |
| Type | Crown Profile Shovel Bucket Tooth |
| System | XSC12 Series |
| Weight | 137 kg per piece |
| Compatibility | 495, 7495HD, WH12 Mining Shovels |
| Pin Required | XSC12PSL |
| Packaging | Individual crate |
Note: This is a Crown profile shovel bucket tooth for 495, 7495HD, and WH12 mining shovels. Must be used with XSC12PSL locking pin. Due to significant weight (137 kg), mechanical lifting assistance is required for safe installation. Verify machine model and adapter compatibility before ordering.
