DLP-1887
Product Data Sheet: DLP-1887 Casting Grizzly Bar
Part Number: DLP-1887
Product Name: Casting Grizzly Bar
The DLP-1887 Casting Grizzly Bar is a heavy-duty screening component designed for extreme abrasion resistance in demanding material separation applications. Manufactured with a unique composite construction of white iron and mild steel, it delivers superior wear life while maintaining structural integrity for high-impact screening operations.
| Parameter | Specification |
|---|---|
| Part Number | DLP-1887 |
| Product Type | Casting Grizzly Bar |
| Material Composition | White Iron + Mild Steel Composite |
| Overall Dimensions (L x W x H) | 311 mm × 67 mm × 57 mm |
| Effective Screening Thickness | 50 mm (38 mm + 12 mm wear layer) |
| Primary Material | Abrasion-Resistant White Iron |
| Structural Backing | High-Strength Mild Steel |
Dual-Material Advantage: White iron surface provides exceptional abrasion resistance while mild steel backing ensures structural durability
Optimized Dimensions: 311mm length with 67mm width offers ideal balance between screening efficiency and structural strength
Enhanced Wear Layer: 38mm base thickness with 12mm specialized wear layer extends service life in high-abrasion applications
Impact Resistance: Withstands heavy impact from falling rocks and materials in primary screening stations
Cost-Effective Screening: Extended service life reduces downtime and replacement frequency, lowering operating costs
Primary screening stations in mining and aggregate processing
Heavy-duty grizzly screens for primary material separation
Rock sorting and scalping applications
Replacement for OEM grizzly bars in demanding operating conditions
White iron composition provides hardness of 500-600 BHN for maximum abrasion resistance
Mild steel backing ensures structural integrity under heavy load conditions
Composite construction prevents catastrophic failure while maintaining screening efficiency
